"It must be considered that there is nothing more difficult to carry out, nor more dangerous to conduct, nor more doubtful in its success, than an attempt to introduce innovations. For the leader in the introduction of changes will have for his enemies all those who profit under the existing order of things, and only lukewarm supporters in those who might be better off under the new."

Niccolo Machiavelli, "The Prince and The Discourses", Chapter 6,
written in 1513, the same year Juan Ponce de Leon landed in Florida.

My 2012 Nissan LEAF purchased December 2011.

Table of Contents Charging Charging Safety Charging Failure Key Fob Cover 12 volt Accessory Battery Operating Cost Capacity loss emergency power Tax Credit LEAF Pickup Truck LEAF Box Range Extender After placing my $99 reservation April 19, 2010 we received our first production electric car from Hill Nissan in Winter Haven, Florida on December 14, 2011. It was worth the wait. At the time we decided to purchase the LEAF there wasn't much selection in production electric cars. We looked at the Chevy Volt but it was much more expensive. We didn't like the limited electric range or the gas engine that we would almost never use. We also considered the Ford Focus electric. But we couldn't find one at that time. If I could have found one, I might have bought it. I preferred the liquid thermal management system. Although I did not like the placement of the battery, I could have lived with it. The decision to buy the LEAF was based on my experience owning and driving my electric truck conversion which had been on the road almost four years when we were making the final decision. Typical round trips in the truck were less than ten miles with occasional trips of twenty miles or less. The longest trip in the truck was 41 miles on a single charge. My reasoning was that the LEAF at its worst with a seriously depleted battery would match the range capabilities of the truck at its best. This seems to be the case. After almost six years the LEAF has lost about two "bars" or about 14 miles of EPA range leaving about 58 miles of EPA range on a single charge. Of course it is higher in local driving which is how it is used. So the car far exceeds our routine needs of ten or twenty miles and is equal to an occasional trip in excess of the trucks longest trip. In all other respects the LEAF far surpasses the truck. It has features like a backup camera, garage door opener in the rear view mirror, auto dimming rear view mirror, heated seats, USB port and electric parking brake among others. The electric brake is important for my wife who is not strong enough to deal with a mechanical hand or foot operated parking brake. Used LEAF prices are very attractive. We have a friend who purchased a 2015 LEAF with 16,000 miles and full battery capacity for $8,000. In cooler or moderate climates the batteries in these cars hold up well over time. but in warmer climates like Arizona or Florida, they don't last as well. But still even in Florida, if your range requirements are modest these cars can provide low operating cost transportation. The other thing to keep in mind is that LEAF battery chemistry improved in 2013 with the introduction of the "Lizard" battery which is somewhat more heat tolerant. In hot climates, I would suggest an EV wth liquid cooled thermal management if you have more demanding range requirements. Our LEAF is now almost six years old. We have never spent a penny on repairs. Operating costs for us are limited to the cost of charging. Since February 16, 2015 when we installed our 5.4 kw solar array, our charging cost is zero. Charging I had the LEAF portable cord that came with the car converted to 220 volts. We have used this cord over the years at both 110 volts and 220 volts at home and in the early days at 110 volts while traveling. We have never installed a wall mounted EVSE. I did have an electrician install a NEMA L6-20 receptacle with #6 wire so the receptacle could be upgraded in the future. I also have a NEMA 14-50 outlet I installed earlier for the truck. EVSE Upgrade converts LEAF portable charge cord to 220 volts How fast can you Charge an EV at 220 volts? It depends on the car. Two important factors are the ampere rating of the onboard charger and the efficiency of the car. Assuming an efficiency of 3 miles per kwh, at 16 amps you can assume that you will recover about 10 miles of driving for each hour of charging. At 32 amps you can assume that you will recover about 20 miles of driving for each hour of charging. We have this from Tony Williams of Quick Charge Power 16 amps or less: Nissan LEAF (all 2011-2012, 2013 - newer with 3.3kW charger), Chevy Volt, Chevy Spark EV, Toyota Prius Plug-In, Ford C-Max Energy, Ford Fusion Energy, ZERO motorcycle (2015 and newer with J1772), Brammo motorcycle, Smart Electric Drive until 2016, Ford C-Max Energi, Karma Fisker, Mitsubishi iMiev, Cadillac ELR, Porshe Cayenne S-E, Porsche Panamera S-E, Honda Accord Plug-In. 28 amps: Nissan LEAF (2013 and newer at 28 amps with "6.6" charger) 30 amps: VW eGolf, Kia Soul EV, BMW i3 and i8, Ford Focus Electric, Fiat 500e, Honda Fit EV, Fiat 500e, Smart (2017 - newer) 32 amps: Tesla Model 3 with 220 mile EPA range Chevrolet Bolt EV 40 amps: Tesla Model 3 with 310 mile EPA range Tesla Model S (2012-2015) Mercedes B-Class ED / B250e Toyota RAV4 EV (2012-2014) EVSE Charging Safety Relevant section of NEC: Section 625.18 - Requires that EV supply equipment include an interlock that de-energizes an electric vehicle connector and its cable whenever a connector is uncoupled from an electric vehicle. Section 625.19 - Requires that EV supply equipment have a means to automatically de-energize the cable conductors and electric vehicle connector upon exposure to strain that could result in cable rupture or separation of a cable from the electric connector and expose live parts" Don't be Shocked, But EV Charging is Very Safe Onboard charger failure If my onboard charger failed in my 2012 Nissan LEAF, I would consider a portable 10 KW Chademo charger. This would be a little bit cheaper than a new replacement onboard charger installed. This requires no changes to the car. his would constitute a significant upgrade from 3.3 Kw to 7.2 KW. his can be used with any EV. 10kW CHAdeMo standard mobile EV DC Fast charger Portable CHAdeMO or CCS Combo DC Quick Charger. 10kW CHAdeMo standard mobile EV DC Fast charger Owners Manual Key Fob Cover Sometimes when I have the key fob in my pocket and I lean up against the car, I set off the alarm. I bought this cover and put the key fob in backwards with a piece of stiff paper over the buttons. This would be a problem if you use the key fob buttons which I never do. In any case it is a good quality well fitting cover even if used as intended. Key Fob Cover 12 volt Accessory Battery Maintenance If you do not drive and/or charge your traction battery every day, your 12 volt accessory battery is subject to sulfation due parasitic loads on the accessory battery even when the car is off. This can happen even if you drive daily but you trips are only two or three miles and you charge your traction battery every two weeks or so. Short trips don't give the charging system (DC to DC Converter) enough time to bring the 12 volt accessory battery up to full charge (12.8 volts for AGM Bolt and 12.7 volts for SLA LEAF). Sulfation is , a build-up of lead sulfate crystals, and is the number one cause of early failures of lead-acid, sealed, AGM or flooded wet batteries. This is a normal result of discharging and is reversed by the charging process. However, sulfates in a lead acid battery left in a discharged state harden and eventually crystallize. This makes charging to full capacity difficult and eventually impossible. The question has been raised, just exactly what are these parasitic loads and what happens when the 12 Volt battery can no longer support them. Parasitic loads draining the 12 Volt accessory battery include but are not limited to: The theft control system, Door lock Entry system, Traction battery Thermal management system, The 12 Volt accessory battery maintenance process, Internet access via the "My Chevy Bolt APP". The loss of any one of these systems can be problematic. It is particularly confusing When the accessory battery is low and the car starts but one or more of these systems is not functioning properly. Strange things happen like the center display is not functional or you cannot shift out of park. If the accessory battery is dead, you may not be able to enter the vehicle because the door lock system is not operational. This is not cheapest but it is an excellent 12 volt accessory battery conditioner, charger and trickle charge maintainer. I have used several chargers and trickle chargers, but this is the best. CTEK (56-864) MUS 4.3 12 Volt Fully Automatic 8 Step Battery Charger This will condition and charge if necessary then maintain a trickle charge. It is small and compact and replaces separate chargers and trickle chargers. If you don't drive every day this keeps your accessory battery in good condition. I have two, one for my LEAF which is seven years old (12/2018) with the original 12 volt battery. The other I use on the Bolt. This not necessary if you drive and/or charge every day. Both processes maintain the accessory battery. It is worth mentioning that many strange symptoms in electric cars are the result of a poorly maintained accessory battery. It is a good practice to check 12 volt battery condition occasionally. Keep in mind that the Chevy Bolt has an AGM accessory battery. Be sure to set the charger to AGM battery Maintenance. Monitoring 12 Volt condition With repeated short trips or intermittent use of your EV it is important to monitor the 12 Volt accessory battery condition. This is best done by keeping aware of the 12 Volt battery voltage. 12.7 volts or higher is a fully charged Accessory battery. To facilitate monitoring status and easy accessory battery maintenance, I use a permanently wired plug to connect the trickle charger and a permanently wired Voltmeter. If you notice a decreasing battery voltage below 12.7 volts, you should test the battery with a Battery Load Tester (see Parts List below). The fact that the car starts after several days of being idle does not mean you don't have an issue. Each time the car sits for an extended period of time, a small amount of battery capacity is lost due to sulfation. The effect is cumulative increasing the amount of lost capacity each time. Eventually the remaining capacity is insufficient to sustain parasitic loads during idle periods of as little as 3 days. It has been argued that it is not necessary to be concerned about the accessory battery State of Charge in the Chevy Bolt because the Bolt automatically charges the accessory battery every 3 days. The following quote has been used as the justification for this approach. "If the car is not plugged but has been turned on within the last 30 days, it will wake up every 3 days to check the 12V battery and if the main battery is at least 40 percent full it will begin charging the 12V battery for 45 to 90 minutes." This Service Manual quote is from the following article. Revealed: secrets of the Bolt EV service manual I have left the Bolt for 7 days without driving or charging the car. I have observed that the car accessory battery was not charged during the period. After 7 days without charging, a discharged battery will result in sulfation not easily reversed by the normal charging process. I believe the Bolt algorithm waits too long and lets the voltage drop too low before charging the accessory battery. I have waited a long time for my copy of the service menu Because it was not available. This is what it says. The Service Manual confirms my suspicion. Doing nothing when unplugged and idle until the 12 Volt accessory battery reaches 12.0 volts is too low. What the Bolt is doing is helpful. It is necessary but not sufficient. This will prevent the 12 volt battery from going completely dead in many cases. But it is not a routine for maintaining a healthy 12 Volt accessory battery. The Bolt is much better at maintaining the 12 Volt accessory battery when the car is plugged in to a J1772 EVSE. The proof is in the pudding. I have driven 3 production electric cars. 2 of them are 2012 models. My Nissan LEAF and my RAV4 EV, which I no longer own, are both 7 years old with the original 12 Volt accessory battery. At the same time there is a multitude of evidence that cars which are not driven and charged every day need to have their 12 Volt accessory battery replaced in less than 3 years. One need only refer to the online forums for both the LEAF and the RAV4 EV. The Chevy Bolt has not been around long enough but we are seeing early evidence of similar problems with the Bolt. The Nissan LEAF also has a function intended to maintain the 12 volt accessory battery while the car is unplugged. Like the Bolt this function is not completely effective. Overall the LEAF not completely adequate at maintaining the 12 Volt accessory battery even when the car is plugged into a J1772 station. The accessory battery maintenance functions in both the Bolt and the LEAF are useful but not apparently intended to eliminate or even reduce lost capacity due to sulfation. It seems their intended purpose is to assure that the car will always be able to start. This is accomplished by using the DC to DC converter to charge the 12 Volt battery using the traction battery as the source whenever the accessory battery becomes alarmingly low. Ironically This 12 volt battery voltage monitoring function adds to the load on the 12 volt accessory battery. The evidence is clear. A neglected 12 Volt accessory battery which is not maintained at full charge will fail early whether it is a piston vehicle, Hybrid, a plug in hybrid or a battery electric vehicle. Here I have the plug and Volt meter pulled out of their normal resting position so they can be easily seen. Here is the plug and voltmeter in their normal resting position. Precision and Accuracy I use this larger meter for precision. This meter shows 2 decimal places where the permanently wired meter only shows 1 decimal place. This meter has several functions other than just showing voltage. I am using only the voltage capability. Although this meter has 2 decimal place precision it is not perfectly accurate. I have checked the voltage with my Fluke meter and it is consistently 5/100 of a volt low. Although it is showing 12.73 volts in the picture it is actually 12.78 volts. I use this meter to check the accessory battery voltage every night before I go to bed when I am home and the accessory battery is not already charging. The permanently wired meter only has one decimal digit precision which makes it more difficult to follow exactly what the rate of decrease in voltage is from day to day. Long Term Airport Parking If you park in long term airport parking or similar situation without access to an outlet, you may be interested in this alternative. In order to increase the likelihood that your accessory battery will not discharge while sitting idle, you can remove parasitic loads by disconnecting the 12 volt accessory battery. This device when connected to the accessory battery will facilitate that process. You simply turn the knob to disconnect the battery. This process is not without its drawbacks. You should open the hood and lock the car before disconnecting the battery. Reentry will require the key inside the key fob to open the door and release the hood latch so you can reconnect the battery. This approach should not be used in extremely cold or hot weather because you defeat the cars ability to maintain traction battery temperature. Traction battery health is more important than accessory battery health. This approach is a poor alternative to plugging into it J1772 station or using an accessory battery maintainer. This is what the owners manual has to say about storage of the Bolt. Vehicle Storage Up to Four Weeks Plug in the charge cord. Four Weeks to 12 Months o Discharge the high voltage battery until two or three bars remain on the battery range indicator (Battery symbol) on the instrument cluster. o Do not plug in the charge cord. o Remove the black negative (−) cable from the 12-volt battery and attach a trickle charger to the battery terminals or keep the 12-volt battery cables connected and trickle charge from the underhood remote positive (+) and negative (−) terminals. See Jump Starting - North America Page 295 for the location of these terminals. Summary Modern automobiles of all types place a parasitic load on the 12 Volt accessory battery. When these vehicles are driven daily and if Plug-in type are charged daily, they will be more or less trouble free depending on the accessory battery charging system in that vehicle. On the other hand if the vehicle is subject to repeated idle periods of 3 days or more, 12 volt accessory battery capacity will be lost. Eventually this will result in a dead accessory battery and the associated inconvenience. This inconvenience can be avoided with a minimum amount of 12 Volt accessory battery voltage awareness. However it can be eliminated with a more proactive battery maintenance program. For those unconcerned about the life of the 12 Volt accessory battery and the need to replace it more frequently, awareness of the accessory battery voltage can help the owner to know when to replace the accessory battery before he is inconvenienced. The fact that an automobile starts is not an indication that the accessory battery is at full capacity and in a healthy condition. AGM Lead acid batteries are subject to sulfation the same as any other lead acid battery . If you have lithium ion accessory battery replacement available for your car, and it is compatible with your cars charging system, it will not be vulnerable to this type of failure. Although the Chevy Bolt is designed to minimize this problem it is not completely effective. Because electric cars will start with 12 Volt accessory batteries at far lower voltages than piston vehicles, many strange symptoms present themselves at these very low accessory battery voltages. When these events happen it is not always obvious that the cause is the 12 Volt accessory battery. Systems other than the 12 Volt battery are often suspected first making the problem even more troublesome. In conclusion, it is best to have at least an occasional awareness of 12 Volt accessory battery voltage. However a more proactive approach to maintaining 12 volt accessory battery voltage at a fully charged 12.7 volts would lead to a trouble free driving experience. br> This section may also be relevant to 12 Volt accessory battery and traction battery condition during Idle periods. Parts List Accessory Battery hook up quick disconnect cable. Y splitter cable. EKM Extension cable. Adapter necessary to connect Battery maintainer to car. Permanently wired One decimal digit precision volt meter. Battery load tester. 12 Volt accessory battery easy cut off switch. Return to My Bolt Operating Cost> It costs about $30 per month for electricity to drive one thousand miles per month or twelve thousand miles per year. This is based on a cost of 10 cents per kwh 3.4 miles per kwh. Some people use a device called a Kill A Watt to measure exactly how many kwh it takes to charge. But it only works for level 1 at 110 volts. I use the ekm-25IDS to track kwh used for charging at level 2 at 220 volts. This meter requires no direct physical connection. It works by induction. I put aNEMA L6-20P on the bottom of the meter with an L6-20R on the top of the meter with the red and black hot wires passing through the meters induction pathway and run the insulated ground wire outside and behind the meter. I plug the meter in the wall and the LEAF portable EVSE modified for 220 volts into the meter's receptacle. You need to record the meter's reading before and after charging and do the subtraction to get kwh used. The meter can not be reset to zero. EKM Metering Inc. Electric kWh Meter, 100A 120/240 Volt, 3-Wire, 60Hz. This meter is capable of measuring 220 volts but requires an adapter for use at 220 volts. Unfortunately this has a maximum of 15 amps. It is ideal for use at 220 volts with the Chevy Bolt EVSE that comes with the Boltand a 2016 Volt. to learn more about using the Chevy EVSE at 220 volts click here. EKM Metering Inc. Electric kWh Meter, 100A 120/240 Volt, 3-Wire, 60Hz. EKM Metering Inc. Electric kWh Meter, 100A 120/240 Volt, 3-Wire, 60Hz. Understanding LEAF Box Extend your range Works by emulating the "hypermiling" technique used worldwide of "coasting" (use of N) and the technique used by the Mitsubishi Outlander B0 to B5 paddles (regenerative braking) – but automatically. LEAF Box review video. LEAF Box install video. LEAF Box home page. Understanding LEAF Capacity loss LeafSpy can help in understanding LEAF battery capacity remaining. This is called SOH (State of Health). This requires the App on an IOS or Android phone or tablet. The IOS App costs $19.99 and the Android App costs14.99. Also required is an OBDII Scanner which plugs into the OBDII Port under the dash on the left side of the steering wheel on the a.LEAF. I use the Veepeak Upgraded WiFi OBD2 Scanner which costs $19.99. Veepeak Upgraded WiFi OBD2 Scanner. I prefer the wifi over bluetooth. I have used this successfully with Leafspy pro on both Apple IOS and Android devices. I like the on/off button also. This is not the least expensive device and far from the most expensive. I like the ability to see tire pressure on all four tires without getting down on your hands and knees. If you plan to buy a used Nissan LEAF, get this first so you can check the SOH (State of Health) of the traction battery. You can see remaining battery capacity as a percent. A must have for LEAF Drivers. You don't actually lose bars. Each blue bar has a white tip on the right end, followed by a space and a white box. It is the boxes that disappear as capacity is lost. On a full charge, you will always have 12 blue bars. If, on a full charge, the number of blue bars is the same as the number of boxes, you have full or near full capacity. You have not yet lost 15% or your first box. This is commonly referred to as having 12 bars (a misnomer, you have 12 boxes). This image shows 4 capacity "bars" lost. But we can see clearly there are 12 blue bars. These bars look like matches or q-tips. It is the white boxes at the end of the top 4 blue bars that have been lost. If a LEAF reaches this state, it has lost 33.75% of its capacity and is eligible for a free battery replacement if it is less than five years from initial purchase. When new each blue bar represents 7 miles. 7 miles X 12 bars = 84 miles. 7 miles X 4 bars =28 miles lost. 84 miles - 28 miles lost = 56 miles remaining. Using LEAF for emergency power The LEAF traction battery can be used to power you home in an emergency by connecting an inverter to the 12 volt accessory battery and turning the car on. I am using the Xantrex 2000 Pure Sine Wave inverter which is actually 1800 watts continuous. The LEAF DC to DC Converter is 1600 watts. Xantrex also offers a Xantrex 1000 Pure Sine Wave inverter which is actually 900 watts continuous. Both inverters will handle peak loads higher than their continuous rating for short periods. Xantrex PROWatt 2000 Inverter, Model# 806-1220 I chose the 2000 because I can use more of the DC to DC rated output continuously. The 2017 Chevy Bolt DC to DC converter is rated at 1.6 KW. the 2012 Nissan LEAF DC to DC converter has a similar rating. The 1000 would be safer but more limited (900 watts). The 12 volt battery will serve as a buffer between the DC to DC converter in the car and the inverter. So the DC to DC Converter won't see small peaks in demand. As a further precaution I use an AC power strip with a 15 amp circuit breaker. This will limit the inverter output to between 1.6 KW and 1.8 KW. This will prevent any large spike in current demand from reaching the inverter. This combined with a little common sense about what I plug into the power strip has allowed me to safely use the larger inverter. I am using 600 amp battery clamps with 24" 2/0 battery cables to connect the inverter quickly and easily to the 12 volt accessory battery. I like these clamps because they screw onto the cables with the supplied screws and washers not supplied. The clamps come with two tab copper connectors. These connectors are intended for cables with no lugs attached. Since my cables have lugs, I cut the tabs off the copper connectors. This left me with two copper washers perfectly sized for the screws that came with the clamps. When the lugs are screwed to the clamps you have a good physical 600 amp connection. 600 Amp Battery Booster/Jumper Cable Clamps 2/0 AWG Gauge Red + Black Pure Copper Battery Inverter Cables 2 feet 3/8 in Lugs AC power strip with a 15 amp circuit breaker EV Federal Income Tax Credit An income tax credit of up to $7,500 is available for a new plug-in car purchase. This will likely be available for the Nissan leaf until 2021. Your income must be high enough that you have a tax obligation that is equal to or exceeds the maximum amount your car qualifies for. The full amount must be taken on the tax return for the year purchased and placed in service. Any unused portion can not be carried over to the following year. Federal Tax Credits for All-Electric and Plug-in Hybrid Vehicles Click here for an estimate of when tax credit might expire for a particular vehicle . EV LEAF Pickup Truck Conversion A diferent type of EV conversion. Start with an inexpensive used LEAF EV. LEAF Pickip conversion.

My RAV4-EV purchased November 2013.

As EPT2, after six years was in need of a new battery pack, and since the field of production electric cars was widening I decided not to invest more in the truck and buy a production EV. With the help of some friends, I found a used RAV4-EV at Downtown Toyota in Los Angeles. Charging As with the LEAF I had the RAV4-EV portable cord that came with the car converted to 220 volts. This cord only supplies the car with 12 amps at 110 volts or 220 volts. I ended up using this cord for both the LEAF and the RAV4-EV because the RAV4-EV is not compatible. EVSE Upgrade converts Toyota portable charge cord to 220 volts The Jesla is a Tesla UMC (Universal Mobil Connector) which Quick Charge Power has replaced the Tesla connector with a J1772 50 amp connector. The Jesla portable EVSE provides maximum output and charging flexability. Improperly Wired 110 Volt Receptacle I have found when traveling in Florida, some motels built prior to 1950 have two prong receptacles converted to three prong both indoors and out. These receptacles often lack ground and sometimes have hot and neutral reversed. A Green light flashing on the Nissan portable EVSE indicates a ground problem. The same is true on the Jesla when a red flashing light is present. In the Bolt cable, a solid red light only indicates electrical system fault: The charge cord has detected a missing or improper ground. If the green light is flashing with a solid red light the charge cord has detected that the plug is overheated. Try another outlet first. Only if a correctly wired outlet is unavailable use one of these adapters pictured to supply a ground. If hot and neutral are correct, your problem is solved. It may not be easy to provide a ground. In this case the quick and dirty solution is to tie neutral and ground together. The EVSE will accept this and charge. This can be dangerous if you do not know which pin is neutral. Proceed with caution and at your own risk. The best approach is to be prepared with the necessary tools and diagnostic equipment. I use the Sperry Instruments GFCI Outlet Tester. Sperry Outlet Tester The problem with any outlet tester is that although they can detect open ground or hot neutral reverse, they can't detect hot neutral reverse in the presence of an open ground. The only tool that can detect hot neutral reverse where no ground exists is the Fluke VoltAlert or another brand's similar tool. Fluke VoltAlert I use the outlet tester to see if there is an open ground. It is likely the case in these old motels. I use the VoltAlert to determine which pin is hot. The VoltAlert should indicate the small pin is hot. If the large pin is hot, hot and neutral are reversed. I have modified a two prong male to three prong female adapter by using a file to file the large prong down to the same size as the small prong. This allows the adapter to be inserted upside down thus correcting the reversed polarity. The last tool in this kit is an adapter I made which is a NEMA 5-15P to a NEMA 5-15R. This is wired internally so that ground and neutral are tied together. When this adapter is plugged into a properly polarized groundless outlet, or when plugged into my upside down adapter correcting polarity in a groundless revesed polarity outlet, you have a NEMA 5-15R which will be acceptable to your EVSE. Safety None of the practices you find here are recommendations and in no way warrantied by me. I am simply sharing my experience. They say nothing succeeds like success. If you want to try to duplicate my success yourself, you do so at your own risk. Let me address some practices that some will see as safety issues. I am not an electrician. I have a cursory understanding of "the code". I also know that "code" requirements vary by location. When the unusual practices I have used in an emergency are questioned with regard to safety, such questions are not without merit. Safety deserves due consideration. Here are my thoughts on the safety of these practices. There are permanent wiring standards and temporary standards. Temporary wiring standards are more lenient and allow things that are not allowed in permanent wiring standards. For safety reasons it is important that temporary wiring be disconnected and removed from permanent wiring when not in use. It is important not to leave adapters connected to the wall that can safely be used with your EVSE but are not safe for use with other appliances or electronic equipment. Simply disconnecting your EVSE from the adapter while leaving the adapter plugged into the wall is inviting trouble. Store adapters that are only safe for use with your EVSE together with your EVSE. Do not remove safety labels from adapters. Where adapters are unlabeled and are not universally safe and foolproof label them as to their appropriate use. With regard to the issue of an adapter with neutral and ground tied together, it has been said that this adapter will compromise the grounding system in the permanently wired system it is plugged in to. I use this carefully labeled adapter only in an emergency in an outlet I have carefully determined to have no ground. The safety principle that applies in this case is that you can't compromise the grounding system in a system that has no ground. If you do not fully understand these practices or are not comfortable with the safety of them, do not use them.

My Chevy Bolt purchased April 2017.

Table of Contents Charging Charge Port Light Charging Etiquette Hilltop Reserve Transport Mode Radio Range Loss of Propulsion Shifting in the Bolt Brake lights in L mode Dash and Mirror Glare Key Fob Cover Trunk 100% ECTRIC Emblem emergency power 12 volt Accessory Battery 110 V to 220 v Super Sport Emblem Towing MPKWHe Dash Light Cargo Cover Seat Pads Garage Door Opener Tire Rotation Dual Dash Cam/Mirror Cabin Filter 12 Volt AGM Battery Fuses Traction Battery Life Charging Interrupt Alarm/a> Door Chime Volume Camping in your Bolt I was planning a Florida to New York road trip on the auto train in the RAV4-EV when I attended an event at Maher Chevrolet in St. Petersburg, Florida. My initial reaction was it was a great car but I had no intention of trading my RAV4-EV at that time. As I continued planning my New York trip of about 1,600 miles of driving, I could see that the trip would be much easier in the Bolt. After much soul searching, on April 3, 2017 I went back to St. Petersburg and purchased the Bolt LT. Who is buying the Bolt? "70 percent of Bolt EV buyers are new to the Chevrolet brand" "33 percent of Bolt EV owners did not own an alternative-fuel vehicle before purchasing the electric car" "97% of owners report the car's range exceeded expectations" "56% of Bolt buyers cite range as the No.1 reason for purchase" Charging If you drive less than 50 miles a day you can charge overnight at 110 volts and 12 amps on a dedicated circuit or a circuit with no other appliance running on that circuit. If you drive less than 100 miles a day you can charge overnight at 220 volts and 12 amps using the Bolt portable charging cord that came with the car and an adapter in an existing 220 volt outlet or one you have installed. I only used this a few times for testing purposes because it is limited to 12 amps and the LEAF cord supplies both the LEAF and the Bolt with 16 amps. Is it safe? What's inside? Adapter allows Bolt portable charge cord to be used at 220 volts. Click the link below for the best alternative. Adapter allows Bolt portable charge cord to be used at 220 volts. The EVSE that came with the car never pulls more than 12 amps from a 240 Volt source. As such a L6-15 will be more than enough. However, if you think you ever might replace the EVSE that came with the car with another EVSE such as a Clipper Creek HCS-40P or the HCS-50p with a NEMA 14-50 plug,then you may want to just install the 14-50 now. Using a higher current outlet for a lower current device, although it will work fine and not trip the breaker, risks a failure in the lower current device not tripping the circuit breaker causing the device to continue drawing excessive current and failing catastrophically with a possible fire in the device. EVSE failures causing fires are very unlikely. The greater the disparity between the EVSE draw and the outlet rating, the more likely a failure in the EVSE will fail to trip the breaker and become catastrophic. Clearly, the disparity in ratings will not be the cause of any failure. The low draw of the cord that came with the car makes this arrangement somewhat concerning when using low rated EVSE in high rated outlet. When a higher rated outlet is used it can be installed with correct wire for the outlet being installed and a breaker rated 20% higher than the expected draw. If and when the outlet is to be used with a higher rated EVSE, the circuit breaker can easily be upgraded. Extension Cord Heavy Duty 10 guage 25 foot extension cord. Upgrading a 110 volt circuit to 220 volts This is useful when the distance from the circuit breaker panel to the location of charging Is very long and expensive, but an existing 110 volt outlet exists. You can use an existing wire for a current 120 Volt outlet of 15 or 20 amps and replace breaker with the appropriate 15 or 20 amp 220 Volt Circuit breaker and replace the outlet with the appropriate 6-15 or 6-20 outlet using the existing wire. If the 120 Volt outlet is not a dedicated circuit, you may have to sacrifice the other outlets on the circuit. Having done that you can use the charge cord that came with the car with an adapter to charge at 220 volts and 12 amps. How to Double the Power of a Standard Wall Outlet. Using Tesla Destination EVSE I purchased the Jdapter for my trip to New York in the Bolt. It allows the Bolt to charge at its maximum rate of 32 amps. Most public level 2 charging stations are 30 amps or less. Jdapter allows the Bolt or any J1772 EV to charge at a Tesla destination EVSE. Global DC Quick Charging Although this is posted here in the Bolt section, it has general applicability. If you are driving a Battery Electric Vehicle (BEV) on road trips beyond the range of your car in the US, there are some things you should understand. This topic is complex. If you want to understand charging in general and quick charging in particular world wide. See the link below. If your driving is limited to the US, you will encounter Chademo, CCS and Tesla superchargers. Typically Asian manufacturers selling cars in the US provide a Chademo Quick Charge port although, some Asian manufacturers are now using SAE CCS. US and European manufacturers selling cars in the US provide the SAE version of the CCS Quick Charge port. Tesla cars sold in the US provide the US Supercharger port. With a Tesla provided adapter, Tesla cars can use Chademo Quick Charge Stations. There are many Chademo only Quick Charge Stations in the US. Most of the newer non Tesla Quick Charge Stations are both Chademo and CCS in the US. Chademo is standard world wide. A Chademo car can Quick Charge at any Chademo Quick Charge Station anywhere in the world. A US CCS car can not Quick Charge in Europe. A US Tesla can not supercharge in Europe. "Electric Vehicle Home Charging Basics" "A Field Guide to electric vehicle service equipment" "The Ultimate Buyer’s Guide To Home EV Chargers: Plus Top 5 Picks" Winter time range extender Winter time range extender Charge Port Light When cut to the right length this item fits perfectly around the perimeter of the charge port. I purchased the green. I got mine from Home Depot. Home Depot LED Necklace Chevy.com LED Necklace Or this as an alternative or in addition to the LED necklace. Or this attached to the inside of the charge port door. This video shows how the GM Charge port illumination looks In practice. See link below to purchase. Or this from GM A;so this from GM GM charge port Installation instructions. Charging Etiquette EV Charging Protocol Card Tips Hilltop Reserve If you want to enjoy maximum regen right from the start after charging your 2017 or 2018 Bolt, avoid doing a full 100% charge by using Hilltop Reserve. This will end the charging process at between 87% to 90% leaving the battery in a state where it can accept the additional charging from regen. This is especially useful if you live on a hill top. Some people use Hilltop Reserve to prevent 100% charge and preserve battery life. Charging yo 80% Here is an interesting way to set the 2017 or 2018 Bolt to charge to 80%. This requires an understanding of your rate of charge and how much time it takes to charge to 80% or whatever limit you want. This works well if you re routinely discharge to the same level and wish to charge to the same percent. If you routinely discharge to widely different levels, this would be a cumbersome way to limit charging. To temporarily override a delayed charge event, unplug the charge cord from the charge port and then plug it back in within five seconds. A single audible chirp will sound and charging will begin immediately. To cancel a temporary override, unplug the charge cord, wait for 10 seconds, and then plug the charge cord back in. A double audible chirp will sound and charging will be delayed. View Eric Way's video for the procedure to limit charge to 80%. here are my calculations for charging my 2017 Bolt LT to 80%. In actual practice I find That if I start the charge at 131 miles It will finish At 212 miles. To finish at 75% I would have to start the charge at about 120 miles. As of 2019 the Hilltop Reserve feature is replaced by the Target Charge Level feature which allows you stop the charging process at any point between 40% and 100% in 5% increments.This provides much more control compared to the previous Hilltop feature. Scheduled Charging Interrupt If there is a power failure or if you unplug your charging cable while the car is locked during scheduled or immediate charging, the Car Alarm will go off. To view and prevent this alarm, touch Energy and then touch Energy Settings. Use the arrows to scroll through the list. Find Charge Cord Theft Alert: This feature allows the Theft alert to sound when there is an attempt to remove the 120V portable charge cord and the system is armed. Set the charge cord theft alert feature to On or Off. Also related. Charge Power Loss Alert: This feature allows an alert to sound when the vehicle is charging and loses power at the electrical outlet. Set the charge power loss alert feature to On or Off. Charge Status Feedback: Set the charge status feedback feature to Horn Chirps or Off. Loud Door Chime To adjust the door chime volume, under settings find Vehicle then Comfort and Convience then Chime Volume This allows the selection of the chime volume level. Select + or - to adjust the volume. Page 143, 177 in the owners manual. There is a limit to how low the volume can be set. Camping in your Bolt To initiate a untethered, long duration parking situation with 12V power, climate control, and WiFi available, place the vehicle in neutral, apply the parking brake, and do not exit the vehicle via the driver's door. Regen During Full Charge The question has been asked,"Where does it go?" referring to generated braking power when you are fully charged. There is no generated power. The wheels turn the motor which acts as a generator, but the generator is not connected to the battery when fully charged to prevent over charging. Therefore there is no load. Without a load, the motor now acting as a generator as it is turned by the wheels produces an open circuit voltage but no current is flowing. Therefore there is no power. Power is measured in Watts. Watts equals volts times amps. Current is measured in amps. No current, no power or drag or braking power applied to the wheels. So where does the generated breaking power go? Nowhere. No breaking power was generated. Transport Mode The intent of the feature is to prolong battery stand time. You may want to use the mode if the vehicle is going to be stored. The method to turn the mode off is the same to turn the mode on. To turn the Transport Mode On/Off, 1- Start the vehicle (as indicated by the green Ready light), 2- Activate the hazard flashers, 3- Press and hold the brake pedal, 4- Tthen press and hold the Start/Stop button at least 15 seconds. The "Transport Mode On/Off" message will appear on the DIC. 5- Then turn the hazard flashers off. 6- Allow the vehicle to sleep at least 2 minutes prior to restarting. Note: Normal Vehicle Diagnostics and Service Procedures Should Not Be Performed when Transport Mode is Active. Turn Off Transport Mode Prior to Performing System Checks or Service Procedures. When the Transport Mode is on (active), enter the vehicle using the steps below. 1- Attempt to unlock the vehicle with the FOB. 2- If the vehicle is not responding to the FOB, press the PEPS door handle switch a few times (if equipped) then attempt to unlock the vehicle with the FOB. 3- If the vehicle is not responding to the FOB, the key must be used to enter the vehicle. 4- Turn the Transport Mode on/off using the appropriate procedure above. Radio The radio in the Bolt comes on every time you start the car. For many, I'm sure, this is a nice feature. For me it is annoying. I don't listen to the radio. I know I am not the only one. Others have the same complaint. You can press the center of the volume knob and this will silence the radio until the next time you start the car. Another choice is to turn the volume all the way down. The problem with this is you won't hear other audio functions like OnStar, hands free cell phone calls or cell phone navigation. The following is the best solution. To silence the radio from car start to car restart. Start the car and while the radio is playing set the volume to an acceptable level. 1. Press (Home- little house icon), 2. then touch (Icon View - little circle with four dots). 3. Touch Audio, 4. then Source. 5. Touch SXM. The most recently listened to SXM channel is displayed. 6. Select SXM channel 0 using left arrow Tire Rotation Nice Video on tire rotation. When it comes to tires , how old is too old? This should be considered when buying new tires or when tires have been in service for many years. "Oddly enough, there's no standard in the United States, but Tire Rack cites recommendations from the British Rubber Manufacturer's Association (BRMA) and the Japanese Automobile Tire Manufacturer’s Association (JATMA) on its website. Per BRMA, unused tires over six years old should never be put in service, and all tires should be replaced after 10 years from their date of manufacture. JATMA recommends inspection after five years and replacement after 10, regardless of treadwear and overall condition." When it comes to tires on classic cars, how old is too old? Range "The Bolt EV is tested in its standard Drive mode, which represents the lowest amount of regenerative capability; Low mode, which ratchets up braking capability, recaptures more energy and could make for even better driving range in the real world." Home on the Range: 2017 Chevrolet Bolt EPA Rated at 238 Miles of Range Long Range Trip Video Eric Way's Chevy Bolt EV 480-Mile Trip (50 mph Average Speed). Long Range Trip Charge Time Video Eric Way's Trip Planning as it relates to charge times. Range When Low This is how you determine the reserve range remaining When you have exhausted your range and the drivers display shows the word Low where range normally appears to the left of the speedometer. 1 - Press the power button to turn the car off. 2 - Open the driver's door. 3 - Close the driver's door. 4 - Open the drivers door a second time and the range will replace the word Low. When you close the driver's door the second time the range will disappear. Traction Battery Life The Secret Life Of An EV Battery. . This chart applies the data from the article to Chevy Bolt alternative if Charging routines. Heading to discharge Based on the article, the optimum Charging routine Is a maximum of 75% Had a minimum discharge Of 25%. I am using the second best alternative Charging 275 percent and discharging to 45%. This is most convenient for me. EV LION Battery Maintenance. . Eric Way's 70,000 mile Battery Degradationvideo. Are you killing your lithium batteries? . Loss of Propulsion Although there have been some posts elsewhere about the use of Torque Pro with the Bolt and lots of talk bout loss of propulsion due to one or more weak cells, I haven't seen Torque Pro used to display all 96 cell group voltages in a single panel. Here is the link you need to setup Torque for the Bolt. Sean's Bolt pids for Torque Pro. I set mine up on my ASUS Transformer Prime Android tablet. I found this to be too slow so I purchased a Chinese tablet EBay for $100. It is a Beneve M1031, 10.1 Inch Google Gaming Tablet PC Android 7.0 Quad Core Dual Camera Wifi 32GB. It is much more responsive than a transformer prime. I use the Veepeak Upgraded WiFi OBD2 Scanner which costs $19.99. Veepeak Upgraded WiFi OBD2 Scanner. The task of setting up the display of 96 data points with two digit precision took some time, but is worth the effort. I am happy to share the layout if you want it. Download and store this file in your hidden torque directory. Knowing my pack is healthy now and being able to monitor voltages in the future makes me much more comfortable with the Bolt. Especially on trips. The car was at 76% SOC when this data was captured. Shifting in the Bolt After starting the car the initial shift requires you to press and hold the button on the side of the lever with your thumb. This is necessary whether going into Drive or Reverse. All shifts into Reverse require that you press the button on the side with your thumb while shifting. However, you can toggle between Drive and Low without using that button. Simply pull back on the lever. You can shift to Neutral by pushing forward the shift lever. Brake lights in L mode One peddle driving is engaged by puttin the shift lever in "L". People sometimes express concern that if you don't use the brake peddle the brake lights wont come on. Not to worry, brake lights work just like you were using the brake peddle. Once you are stopped they turn off. So put your foot on the brake while waiting for traffic light to change. Video demonstrates brake lights when using regen. Maintenance Cabin Filter Cabin Filter replacement video. AnotherCabin Filter replacement video. Bolt Cabin Filter replacement part. Fuses 2017 Chevy Bolt Fuses   Most of the fuses in the Bolt are Micro2 two blade. There also fouur Low Profile LP Mini 2 amp fuses. Micro2 fuses are not made rated at 2 amps. There are also J-Case and M-Case fuses along with various Relays and only one 15 amp Circuit Breaker.   I have created two charts not available elsewhere. There is one chart for each Fuse Box. One is under the hood and one is under the dash. Both are on the driver's side. Each chart provide in one place the type of fuse and its rating in amps along with a full description of its purpose for each fuse location. The entries are in the order of fuse location number.     This chart may help when shopping for fuses. 12 Volt AGM Battery The Chevy Bolt 12 volt Absorbed Glass Mat (AGM) accessory battery is critical to a wide array of on board telemetry, monitoring and control systems. Because the Bolt has no piston engine to crank at startup, instantaneous power demands are dramatically lower than the demands of of a conventional car.   This means when properly maintained, the 12 volt AGM accessory battery can last much longer than the battery in a conventional car. This could be ten years or more. However, when neglected and abused failure can occure after just a couple of years. Sometimes Bolts sit on dealers lots for months with no attention before they are sold. For more information on this see Accessory Battery Maintenance   The more deeply a lead acid battery of any type is discharged the fewer the number of charge cycles.   Capacity loss will be experienced due to sulfation if a lead acid battery of any type is not maintained at full charge. The amount of capacity lost is a function of what Depth of Charge (DOC) the battery is left at without charging. The battery should be charged as soon as possible after discharge. No more than 24 hours.   For these reasons it is important to understand the State of Charge (SOC) of the Bolt 12 volt LN1AGN accessory battery. SOC is best understood by checking the Open Circuit Voltage (OCV) of the battery. The 100% OCV is critical tp preventing lost capacity.   The SOC or more correctly DOC must be understood to get the maximum number of charge cycles from the battery. The deeper the DOC the shorter the battery life.   Here is the label on the top Of the Bolt's Delco LN1AGM 12 Volt battery.     Order the Delco LN1 here. Amazon Delco LN1 AGM Accessory Battery In the absence of a data sheet for the Bolt LN1AGM accessory battery, I am using data from the Universal Power Group UB4D 12 volt AGM battery with which I have first hand experience.   Here is a graphic presentation of OCV vs SOC for the UB4D AGM     I created this chart using the graph above as the data source.   In alternative but less detail source and not particularly related to the Bolt LN1AGM battery either comes from Delco .   Here is a graphic representation Ofcycle life Versus Depths of discharge for the UB4D AGM.   Here is the Delco AGM Guide. Delco AGM Guide Accessories Garage Door Opener The Chevy Bolt does not have a built in garage door opener (HomeLink® Universal Transceiver). Chris leaves the Bolt owner with the problem of deciding what to do with the Remote Control For the garage door. I have used self adhesive Velcro to attach the remote in front of the cup holders on center console. This location for the garage door opener Is extremely convenient For the driver to reach while at the same time being completely Out of the way. View of the center console with the garage door opener in place from the passenger side. View of the center console with the garage door opener in place from above. Dash Cover Windshild glare from the Dashboard can be a problem at times. Some Bolt drivers have found polarized glasses eliminate the glare. I have found that they reduce the glare, but do not eliminate it. Glare is a problem to varying degrees depending on where you live and drive. In northern latitudes the sun hits the windshield at a different angle than southern latitudes. This also varies at different times of the year. And of course different times of day. Polarized sun glasses will help to varying degrees depending on these variables. However for people like me who are required to wear prescription glasses while driving, polarized glasses can be an expensive or impossible nuisance. This product provides an attractive and effective solution. I ordered color #51 which is black suede. Dash Cover - Chevrolet Bolt 2017-2018 Bolt Headlight Sensor and Charging Light Indicator is a standard feature Dash Cover Driver's Rear View Mirror Glare Glare from the white portion of the Dashboard can cause a reflection obscuring the drive's side view mirror at times. Bolt drivers in northern latitudes may not experience this problem for reasons similar to the windshield glare issue. But also they are more often exposed to overcast conditions or in nice weather driving with the window down due to moderate temperatures. This product provides an effective solution. Self adhesive protective felt. It has been on there now for about a year. It doesn't look bad and is adhereing well. Self Sticking Felt Key Fob Cover Sometimes when I have the key fob in my pocket and I lean up against the car, I set off the alarm. I bought this cover and put the key fob in backwards with a piece of stiff paper over the buttons. This would be a problem if you use the key fob buttons which I never do. In any case it is a good quality well fitting cover even if used as intended. Key Fob Cover Key Fob Battery Replacement Here is a video with more important information About changing the battery in the key fob and what to do if you get Locked out of your car because your key fob battery is dead. You will need a CR 2032 Replacement battery. Key Fob VIDEO Key Fob Replacement Here is a source for a key fob replacement. Key Fob Source I successfully added a third key fob using the above key fob source. I had the key blank that came with it cut at a local locksmith using one of my existing keys as the master for $30.00. Once the key was made, I successfully programmed the new key fob using the procedure described on page 36 of the 2017 Chevy Bolt Owner's Manual, "Programming With Two Recognized Transmitters". I followed the instructions carefully and to the letter. Success the first time without any problems. I was surprised how quickly this went. A hint that may help is that in step 4 where it says press power to start the vehicle", the car did not start which perturbed me. I stayed calm and notice that the "Ready to program Transmitter 4" was displayed on the DIC. I was surprised how quickly programming completed. I proceeded to step 5 and finished with no further surprises. Alternate Key Fob Source Once you have your replacement key fob, it will need to be programmed. This procedure is dovumented in the 2017 Bolt owners manual on page 36. See the topic, "Programming Transmitters to the Vehicle." Cargo Area Liner Installation is simple. The most difficult part of the installation is removing the cut outs for the bolts that hold the blocks in place that support the Deck. I used a 1inch wood boring bit in variable speed drill. Place the tip of the drill Bit at the exact center of the cut out area. Turn the pit slowly. It makes a perfect hole be exact size required. Cargo Area Liner - GM (42564933) Seat Pads I have never found a Chevy Bolt seats uncomfortable. But clearly the edges of the seat are hard. This is the best fitting and best looking improvement to Chevy Bolt seat comfort. Seat Pads Modifications Dash Light This is perhaps a poor imitation of Premier Dashboard lighting In my LT. I used the one meter length of the EL Neon tape. It doesn't quite go all the way from end to end as you can see. I ordered the EL neon tape and the tools to install it From Amazon. It is plugged into a USB port on the end of a cigarette lighter adapter. EL Neon tape Tools to install Dual Dash Cam/Mirror BIR 10 Inch Touch Screen Dual HD Dash Cam /  Rear View Mirror   I purchased this product from Amazon for $139 for my 2017 Chevrolet Bolt. BIR Dash Cam/Mirror   This is a high quality no nonsense, no frills, no glitz front and rear high resolution Dash Cam with the added advantage of a rear view display that fits over the existing rearview mirror.   This dual dash Cam "Mirror" replacement does a very good job meeting the basic requirements it addresses.   There are three functions this product provides that I am not using. 1.      My Bolt has a backup camera so I did not connect the rear Camera to the backup lights. 2.      I have turned off the G sensor because I am using a 64 GB SD Card which can hold 2 hours of recording both front and rear. The G sensor locks files on a collision. If you tap the lock icon on the screen, you can lock the file manually. You can also remove the SD Card to preserve the video from the accident. Also turning off the car will prevent further recording. Locked files cannot be overwritten. The G sensor can be set to 3 sensitivity levels or it can be turned off. I found that a bumpy road causes files to be locked. Rather than go through the trouble of trying to find the right sensitivity level I decided to just turn the G sensor off. This assures that recording will loop endlessly without locking any files. 3.      The screen on the rear view display is highly reflective and can be used as a conventional rear view mirror by turning off the display. I live in Florida where it is very sunny and the angle of the sun in winter is very low. This causes objects like seats and passengers to be brightly illuminated resulting in reflections on the display. This makes the display hard to see at certain times of day. I have delt with this problem by using a tablet screen protector on the display to eliminate glare. This has proven to be highly effective. The display was shipped with a protective film over the screen. I removed this and saved it. This served as an excellent pattern for cutting the tablet screen protector to the right shape and size to cover the display.   I purchased Tech Armor Anti-Glare/Anti-Fingerprint Film Screen Protector for Apple iPad Pro 12.9-inch for $10.95 including tax. I chose the screen protector for its price, glare protection and large size. https://www.amazon.com/gp/product/B016B12TSW/ref=ppx_yo_dt_b_asin_title_o02_s00?ie=UTF8&psc=1 Recording Quality   Evaluating video image quality is subjective so I have included short day time and night time videos so you can decide for yourself. Only the bottom half of the rear video is displayed. Http://www.evprogress.com/Day%20Front.mp4 http://www.evprogress.com/Day Rear.mp4 iHttp://www.evprogress.com/Night%Rear.mp4 Http://www.evprogress.com/Night Rear.mp4   Another question that is often raised is, "Can you read license plates." I have included unaltered screenshots so you can decide for yourself. Rcording while parked   When the BIR Dash Cam is wired in the typical way, it turns on when you start the car and turns off when you turn the car off. For this reason it cannot be used to record while the car is parked and the car is turned off.   Also depending on the size of the SD card you are using you may not be able to save all of the recording while the car is parked.   Another consideration is overheating that may occur in extremely hot weather.   I have decided that I would like to record while parked. So I have installed a second 12 Volt Cigarette lighter outlet in my Chevy Bolt. I have added a push button switch which allows me to supply 12 volts to the new 12 Volt cigarette lighter outlet from either a key off 12 Volt source or a key on only 12 Volt source depending on the position of the push button switch. Normally the Dash Cam goes on and off when the car is started or turned off. But if I want to record while the car is parked, I simply press the push button switch and the Dash Cam comes on while the car is off.     I am now using a 256 GB SD card. This can hold 8 hours of recording of both the front and rear camera while parked.   Although I am concerned about overheating in extremely hot weather, I have found from experience that I can leave the car parked outside and recording in temperatures as high as 96 degrees Fahrenheit for 45 minutes without any problem. I have left the camera recording for about 3 hours during a shopping trip with several stops at different stores. Trips between stores with the air conditioning on were able to maintain a reasonable operating temperature for the Dash Cam.   When I am at home the car is parked in an air conditioned garage.     I ordered the push button switch and the 12 Volt cigarette lighter outlet on Amazon.   https://www.amazon.com/gp/product/B019WRH3ME/ref=ppx_yo_dt_b_asin_title_o03_s00?ie=UTF8&psc=1   https://www.amazon.com/gp/product/B01H5C5CB2/ref=ppx_yo_dt_b_asin_title_o06_s00?ie=UTF8&psc=1      https://www.amazon.com/gp/product/B00K0TQ94C/ref=ppx_yo_dt_b_asin_title_o01_s00?ie=UTF8&psc=1   I actually ordered 2 cigarette lighter outlets. I used the mounting bracket from the second one to mount the switch. This requires a washer like adapter because this switch requires a 3/4 inch hole and the cigarette lighter mount has a one inch hole.   I used a Micro2 Fuse Adapter Tap which I ordered from Amazon to connect the switch to the under dash fuse panel.   https://www.amazon.com/gp/product/B0759JVKX6/ref=ppx_yo_dt_b_asin_title_o06_s00?ie=UTF8&psc=1         here are two videos of recording in parked mode. One is of the front and the other is of the rear.   PARKED FRONT PARKED 720 REAR Installation     I found the installation process to go quite smoothly. The most difficult part was the placement of the rear camera.   I followed the recommended routing for the rear camera cable as indicated by the red line in the user manual. I routed the cable across the top of the windshield to the A pillar. Then around the A pillar to the molding over the driver's door-. Then around the B pillar to the molding over the rear driver's side passenger door . Then behind the very wide panel covering the C pillar to the tailgate.   One of the tools in this kit I bought from Amazon was very helpful in cable routing. The Kit is on the left. The tool I used is on the right. https://www.amazon.com/gp/product/B06X942HKC/ref=ppx_yo_dt_b_asin_title_o07_s00?ie=UTF8&psc=1 I routed the power cable across the top of the windshield. Then down A pillar to the bottom and around the A pillar. Then down to the bottom of the dashboard where I routed it to the cigarette lighter.   I mounted the rear camera inside the car at the top of the rear window. The mounting bracket for the rear camera works best on a vertical surface or the underside of a horizontal surface with the camera hanging upside down. Mounting the camera on top of a horizontal surface displays the image upside down on the screen.   I drilled a small hole at the center top of the rear window panel. I used double sided tape and some spacers with a single screw to hold the camera to the underside of the panel at the top of the rear window.   Customer Service Customer service works best by text message. I found this to be prompt responsive and helpful . There is a 12 hour time difference which you have to take into account. Although there are minor language related communication difficulties, I found the service staff to be knowledgeable, intelligent, helpful, and friendly. Text (619) 202-5383.   Operating Temperature There may be some misunderstanding about operating temperature. The dash cam / mirror can operate at temperatures up to 150° F or 70° C ,not 60° F as stated in the owners manual. .   There are some minor drawbacks with this product. 1.      The Splash screen on startup and shutdown is accompanied by a very loud musical tone. The volume of this tone cannot be adjusted or turned off. I would be happy not to hear this sound. 2.      The SD card is difficult to remove. I made a tool to push down on the card to remove it and to push down on the card when it is inserted. 3.      This product is not provided with an SD Card . I ordered 2 - 64 GB SD cards at the same time as I ordered this product. 4.      An inherent problem with any digital rear view "Mirror" display, is that people who wear bifocals will have a problem that they don't have with an optical rearview mirror. People who don't wear glasses may have a similar problem. The problem comes from the fact that objects in an optical mirror appear to be at a distance. Objects on the digital display appear to be near, similar to the distance of the display on the dashboard for the speedometer. When people wearing bifocals look at the speedometer they look down through the bifocal lens. When they look at the rearview mirror they look up through the distance lens. This works fine for an optical mirror. However with the digital display people wearing bifocals are seeing the display through the wrong lens. It may therefore appear out of focus. People with presbyopia will have a similar problem focusing on the digital display that they do not have focusing on an optical mirror. Summary Overall, this is an easy to use dependable dual dash cam. The looped recording provides full time continuous recording front and rear, day and night whenever the car is running requiring no attention at all.   The rear view "mirror" display provides a wide unobstructed view. For me in my circumstances, glare was a problem easily corrected with a glare reducing screen protector. This may not be a problem for others.   The installation was easy. The most difficult part was mounting the rear camera which was manageable. Most of the time was spent with a trial fit at the bottom of the rear window. Once I realized my upside down image would be corrected by mounting at the top of the rear window things went quickly.   Here is a link to the Owner's Manual for the BIR dash Cam. BIR Dash Cam Owners Manual Here is a link to th this review BIR dash Cam in PDF format. BIR Dash Cam Review     100% ELECTRIC Emblem The Bolt is not Obviously an electric car. To the casual observer it looks like any other car. I have added some emblems to both the front and back of the car to make it more obviously an electric car. At the back of the car I have added an emblem that indicates 100% electric. 100% ELECTRIC Emblem Other interesting things to note In this image are the license plate bracket , The Bumper sticker Which states "Why gas up? / Plug In!" and the Chevy bow tie which as been Covered In white vinyl. An emblem has also been added to the front of the car to help identify it as an electric car. Also note the white bow tie. Super Sport Emblem The Bolt is obviously not a Super Sport model. But it's 0 - 260 MPH Time of 6.5 seconds is faster than many super sport models that bore that badge. So has a joke I hated the SS emblem to my Bolt. The first Chevy super sport was the 1961 Impala with a 409 cubic inch engine. 0 to 60 time for this car was 7.8 seconds. The super sport option cost $53.80. Super Sport Emblem Trunk I have removed the insert under the trunk floor and cut the protruding screws short so I can store charging accessories etc. I have a 3/16" aluminum plate cut in half as my new trunk floor. In a rear end collision the rear plate will slide under the front plate. I have stored here my Jesla portable UMC with adapters in a Nissan LEAF case, my Jdapter, a 12 volt tire air compressor, a tire repair kit, a 12 volt booster battery, a 50 foot 12 gauge extension cord, my 110 volt two prong outlet kit, my supplemental adapter kit for outlets not supported by Jesla and some other small items. It has been observed that the foam insert may be part of the rear crash protection. On the other hand it may not be. Consider the shape of the depression. Consider the fact that it is used by GM for the sub Woofer. Consider that my wheel well space is not empty. The space in the photo is mostly empty. But all things considered, I must admit, any modification to an automobile has safety implications. Simply the nature of what you carry in the trunk has safety implications. Better to be safe than sorry. So I would say if you are not comfortable with the safety of this modification, don't do it. If you do, you do so at your own risk. Towing Here is a Chevy Bolt trailer hitch rated for 200 pounds tongue weight and 2,000 pounds towing weight. 2017 CHEVY BOLT ECOHITCH This should not be taken as a recommendation to use the Bolt for towing. This is included for information only. Use the Bolt to tow at your own risk. From the Ownes Manual "Driving and Operating page 199. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. This vehicle is neither designed nor intended to tow a trailer. How to wire the Bolt for connecting trailer lights. Towing Safety The GVWR of the Bolt is 4467 and the curb weight of between 3563 lbs. and 3580 lbs. With a driver and no passengers or cargo, you have a towing capacity of 750 lbs. GVWR for a trailer at best without exceeding the GVWR of the Bolt. If you exceed the GVWR of the Bolt, you will lengthen the car's stopping distance. There is a difference between traveling cross country at highway speeds while towing and driving around town five or ten miles at 35 or 40 mph while towing. Towing safety. Towing Laws Towing laws by State Towing law Table by State MILES PER KWH EQUIVALENT FOR GAS CARS For me, talk about MPGe seems Irrelevant. My Bolt does not use gasoline. They say, turn about is fair play. So I say what is the miles per KWH Equivalent (MPKWHe) for a gas car. I live in Florida with gas prices are 2.50 per gallon and electricity cost 9 cents per kilowatt hour. Plus I have a 5.4 KW solar array which means I am driving on sunshine. This chart is based on gas prices of $$2.50, so it doesn't work Where gas prices are $3.50 or more per gallon. However where gas prices are in that range, electricity prices are also likely to be higher. FWIW You can compare your Bolt to gas cars of different economic efficiencies. > Here is the formula used to create the chart. If you pay more than the national average of $2.50 per gallon for gas or 25 cents (highest entry in chart) for electricity you can use this formula to compute your MPKWHe. For example living in California where gas costs $4 per gallon and Electricity is 12 cents per kilowatt hour off peak and if your gas car is a Prius that gets 50 miles per gallon, then 1/(4/50/.12=1.5 MPKWHe.

There are four kinds of keys for your Tesla model Y. The key card (you will receive two at delivery). The key ring ( optional $125 accessory). The key fob (optional $150 accessory). The smart phone app.

I have all four. I don't use my smart phone as a passive device to lock, unlock or start the model Y. Blue tooth is required for this app function. This runs the phone battery down quickly and shortens battery life. The app can be down loaded at any time but will not be functional until delivery.

I also don't like to use it for active functions like opening the charge port, trunk, hood or summon. The screen is hard to see in the Florida sun, it takes several steps using two hands and you can't do it without looking at the screen.

I prefer the key fob. All I need to do is have it in my pocket for passive functions. Active functions can be done effortlessly with one hand without looking at the key fob. This is particularly important when using summon. I can focus my attention on the progress of the model Y and not the phone.

Double click on the trunk or hood to open them. Long press on the trunk to open the charge port. Single click or double click roof to lock or unlock the model Y. Long press on the roof until hazards flash for summon. Then click the hood or trunk for forward or reverse. Click anywhere to end summon and stop the model Y.

Key fob summon requires the following: On the touchscreen, ensure that Require Continuous Press is disabled (touch Controls > Autopilot > Summon > Require Continuous Press > NO).

I have a very nice stitched leather key fob cover I got from Amazon for $13.90.

The key card is in my wallet. The key ring I wear on my finger. Either of these can be used to open and start the car. Tap the card or ring on the drivers side B pillar to unlock or lock the model Y. Place the card or ring behind the cup holders on the center console to start the model Y.

The card or ring can be used at any time but are particularly useful if your phone or key fob is lost or left behind or the battery is dead or not functioning for any reason.

I prefer the ring over the card because it is more easily accessed.

Key ring link

Key fob case link

:

Key fob link

:

Plug-in, we have the technology, the all electric Tesla Model 3 and Chevy Bolt are the proof.

Over time the purpose of this site has changed from advocating for the feasibility of the electric car to documenting my experience with production electric cars I have owned and driven over the recent years. Ten years ago the only production EV was the Tesla Roadster. The best example of a tried and true EV was the RAV4-EV, many of which were crushed, and last one of which was produced in 2003. Today, in 2017, we have proof of concept in a score of models from a dozen manufacturers. The modern EV has evolved since its revival in 2011 when there were just two affordable plug-in cars from Nissan and Chevy. We have advanced from sub 100 mile cars to plus 200 mile cars. At this point people have questions about their new EV or seek help in selecting the right new or used EV to meet their needs. My purpose now is to share my experience with interested drivers more than persuade those less interested. After viewing the movie "Who Killed The Electric Car?", I was moved to buy my 1999 Ford Ranger and convert it to a battery electric vehicle. It is said that marketing of the EV failed to surface demand from the American consumer. What amazes me, is that as someone who converted my first pickup truck in 1979, as someone interested in the electric car, I was unaware of the entire EV history of the late 90's and early couple of years in the 21st Century. I try to keep up with current events. I never saw the advertising or any word in the news. Surely the systematic crushing of an entire generation of vehicles by a manufacturer is an event of national interest. Where was the media? This is about defining the problems (economy, national security, foreign oil dependency and the environment), understanding the solutions and solving the problems. Although motivation is shifting towards simply choosing the most cost effective solution. The media likes to talk about plug-in electric cars as a niche market and offers as proof that for five years they represent less than 1% of the cars on the road. A further point offered as evidence that plug-in electric car sales are low is that President Obama had a goal of one million plug-in electric cars on the road by 2015. We failed to meet this goal by more than half at little over 406 thousand by year end 2015. The failure to meet an unrealistic goal is not proof of slow growth. In a market where conventional car sales have gone from 17 million in 2007 to 10 million in 2008 and have slowly climbed back to 17 million in 2016, the number of plug in electric cars on the road has doubled five times from 17,000 to 570,000. Plug-in electric car growth is exponential while conventional car growth struggles to reach the pre-recession peak of over 20 million in 2005. The number of plug- in electric cars on the road must double seven times to reach one percent. However the next seven doublings will replace conventional cars. Although it takes seven doubling to get to 2 million and one percent, the next seven doublings are approximately 2%, 4%, 7%, 14%, 28%, 55% and 100%. All of this rapid growth has occurred in a down conventional car market with sub-100 Mile range plug-in electric cars. 2017 is the first year of the plus 200 mile range electric car. We can expect exponential growth to accelerate as the affordable plus 200 mile range cars like the Chevy Bolt, Tesla model 3 and Nissan LEAF hit the market this year and the years to come. We are progressing rapidly regardless of the intentions of the oil industry and the current administration and the media's under-estimation of disruptive technology. Electric cars, renewable energy and exponential growth, all of which are sweeping the nation and the world. This is not just because of consumer concern for the environment but because total cost of ownership is much lower and the product is superior. Already climate deniers are installing solar on their schools and churches. They are buying electric cars for their police. It wont't be long before they are installing solar on their homes and driving their own electric car. Tony Seba: Clean Disruption - Energy & Transportation

My Contribution Is My
Electric Pickup Truck Two
- EPT2

These pictures were taken by Frank Jackson in his car port on Jan 4th, 2008, two days after final assembly. The trip that day, from Southwest Winter Haven to Auburndale, Florida, was 19 miles. The recharge took six hours, consuming about 12 KWH at 13 cents per KWH, for a total of $1.56. This same trip would have consumed 1 gal of gas at over three dollars before conversion to electric. (1200 mile update, my estimate of cost to charge was very high. After reviewing electric bills, it is almost impossible to see any increase when comparing four years bills. Over three months, I can only account for $20.00 over the entire period.)

For now, as a result of over 1200 miles of driving, I feel I have achieved my goal of a plug and drive vehicle with a range of 35 to 40 miles. Although my longest trip exceeds my goal at 41 miles, so far. It is everything I expected. The lack of power steering is sufficiently acceptable that I have no current plan to add it.

Al & Truck 1-08 815.83 KB	Al & truck 2 1-08 611.12 KB
Als rear battery equalizers 827.08 KB	Als rear batteries 910.66 KB
Als electric truck Tailgate 579.51 KB	Under Hood 1.09 MB
Als Truck recharge port 638.96 KB	Charge Port, Charging 1.09 MB
Als electric truck Charging 579.51 KB	Interior, no clutch, Emergency pull, pod 1.09 MB

To be quite frank, although this car is a viable alternative to its gas powered previous life, it is not its equal. The V6 motor I removed was very responsive with the 5 speed transmission. Neither is it equal in pollution or foreign oil dependence. For me, this is the vehicle in which I will do over 90% of my driving.

One thing I am concerned about, is that this car be used as an example of the limitations of electric vehicle technology. The limitations of this vehicle reflect my limitations. For anyone interested in the true limitations of the EV technology, use the Toyota RAV4 EV, the Ford Ranger EV, the Tesla or the EV1 (800 crushed by GM) as the standard.

I converted this vehicle because the automobile industry has abandoned this technology, for reasons I will never understand, leaving me no alternative, but to build an inferior substitute.

Although my car meets my requirements and is a wonderful alternative to pollution and foreign oil dependence, it is no match for GM or Toyota automotive engineering.

Chevron has taken steps to see to it that I can’t have NiMh batteries in my car. I would have bought them if I could have. The result is that my vehicle has half the range it could have. The result is, I imagine, just what Chevron wants. My car looks to be half what it could be, to anyone forming an opinion about Battery Electric Vehicle Technology.

My car is here to show you that battery Electric Vehicles are viable. It should not be used as an example of the limitations of the Technology.

Almost 10 years have passed since this conversion was put on the road and this was written. The outlook for the electric car at that time was uncertain. Things have changed dramatically in a very positive way in the last ten years. In 2007 the Chevy Volt concept was presented and promised for 2010 production. In the end GM came through on that promise but in 2008 it was only a dream. In 2008 Tesla started deliveries of their Roadster EV. For most people in 2008 a conversion was the only electric car choice.

It was in December of 2010 that things began to happen when Nissan and GM began deliveries of the LEAF and the Volt. I reserved my Nissan LEAF on the first day April 19, 2010. I took delivery from Hill Nissan in Winter Haven, Florida on December 15, 2011. The range on this car was 73 miles.

Two years later I purchased a used 2012 Toyota RAV4-EV from Downtown Toyota in Los Angeles. On November 26, 2013 it was shipped to me in Winter Haven, Florida. The range on this car was 142 miles.

About three and a half years later on April 3, 2017 I purchased a 2017 Chevy Bolt from Maher Chevrolet in St. Petersburg, Florida. The range on this car is 238 miles.

On February 16, 2015 we installed a 5.4 kw solar array at our home.

In 2011 17,000 plug-in cars were sold. As of the end of year 2016, 570,00 plug-in cars were on US highways. So we are seeing electric vehicle progress not just at our house, but across the country. The number of plug-in cars have doubled five times in five years. And that doubling has occurred with sub 100 mile cars. Who knows what might happen with plus 200 mile cars now emerging at a dealer near you.

EPT2 Documents

EPT2 Upgrades

Milage Log

EPT2 Video

EPT1

EPT3

Events

"Who Killed the Electric Car?"

"This bumper Sticker is available from" "More stickers and merchandise available at Plug-in America" "Who Killed the Electric Car?" Where is the media, in Austrailia?

A Dying Industrial Town Troy is, in some sense, my home town. I went to Troy High. The history of Troy is not unique in our nation. But it is relevant to me. Troy was an important thriving industrial town at one time. From the downtown train station, you could travel to NYC, Boston or Chicago. Trolleys filled the streets. It had theaters and parks and a National League basball team. It makes you think about what can happen to prosperity and a way of life. Of course this video is not about what Troy is today. People still live happy lives there. But still, this video makes you think about sustainability, and the choices we've made along tthe way. Things will change and they will change based on the choices we make.

Battery Technology

RAV4 EV, EV 95 battery.

Toyota on the RAV4 EV

"Although a significant marketing effort was undertaken for the RAV4-EV, we only sold about 300 vehicles a year. . . technical issues tied to electric vehicles remain a major hurdle. . . .It is cost-prohibitive to replace an EV battery. Although Toyota's electric vehicle sales have proved disappointing, Toyota was able to leverage valuable technology from the development and sales of the RAV4-EV. . . For example, some of the technology involved in the Hybrid Synergy Drive system on the next generation Prius came from the RAV4-EV." How come I didn't know about the RAV4 EV, did you know about it? RAV4 EV Manufacturer Chevron sued Panasonic for making the EV-95 NiMH Battery and Toyota for using it in the RAV4 EV, in the amount of $30 million. Production of the EV-95 NiMH battery stopped and consequently the RAV4 EV. The RA4 EV is running today with the original batteries, many of them have over 100,000 miles. Toyota still uses a smaller NiMH battery in their Prius and Camry Hybrids under agreements with Chevron. Toyota will not make their Hybrids plug-in without consent from Chevron. Toyota can only produce a plug-in vehicle, without permission from Chevron, when they have an alternative battery Technology, or when the NiMH patent runs out in 2014. The events summarized here are actual history and the outcome is history. The nature of the legal complexities that motivate the players involved are speculation and not important. What is important is that we know what is possible. We know, technologically, what can be done, because it has been done. We know what the problems are that need to be solved. We know how to solve them. Finally, we know that the outcome we have is not in the best interest of this Nation. RAV4 EV Final Fleet Report.pdf RAV4 EV User Experiences.pdf Doug Korthof On GM's denial of NiMH and the RAV4 EV
